Waterproof Walkie Talkie IP68 Baofeng UV-9R Plus 10km

Waterproof Walkie Talkie IP68 Baofeng UV-9R Plus 10km High Power 10W Dual Band Two Way Radio UHF VHF Portable Ham Radio UV9RPLUS

IP67 Waterproof & Dustproof

1-35KM Long range for Complicate using environment

Output Power:High/Mid/low power to choose

Key Feature

1) IP67 waterproof and dustproof (Not diving) 2) Relay Forwarding Confirmed (1750 HZ)

3) Dual Band, Dual Display and Dual Standby 4) High &Low Power Switchover

5) Battery Saving 6) VOX Function , Squelch function

7) Wide/Narrow Band Selection 8) Auto-Back Light

9) Dual Band Standby 10) Time-out Timer (TOT)

11) 50 CTCSS and 104 DCS Codes 12) Voice Prompt

13) ANI Code 14) PC or Manual Program

15) DTMF Code 16) PTT-ID

17) ATUO Keypad Lock 18) Busy Channel Lock Function

19) Low Battery Warning 20) Emergency Alarm

21) Priory Scanning Function 22) U/V Cross Band Dual Watch

General

Frequency Range

VHF:136-174MHz UHF400-520MHz

Channel Capacity

128

Channel Spacing

25KHz/12.5KHz

Antenna Impedance

50Ω

Microphone Impedance

600Ω

Operating Voltage

7.4V DC±15%

Frequency Stability

±2.5ppm

Battery

hiher capacity (Polymer Li-ion)

Compatible With American Military Standard(Mil-STD-810C/D/E)

Transmitter(EIA-RS 316B STANDARD)

RF Power Output

10W/higher power

Modulation Type

Radio (65.0MHz-108.0MHz)

Modulation Sensitivity

<15µV

Modulation Distortion

≤3%

Max Freq Deviation

<5KHz

Occupied Bandwidth

≤16KHz

Modulation Feature

±3dB

Spurious Radiation

≤7.5μW

Adjacent Channel Power

≤-65dB

Receiver

Sensitivity(12db SINAD)

≤0.15μ(12dB S/N)

Squelch Sensitivity

≤0.1μV

Audio Power output

1W/16Ω

Audio Respond

-6

Operation Bandwidth

>5KHz

Co-channel Rejection

≥-8dB

Blocking

≥85dB

Adjacent Channel Selectivity

≥65dB

Standby Current

60mA,15mA

Spurious Rejection

≥60dB

Intermodulation Resistance

≥60dB
